FTTH Cable GJXFH(V)

Product Description

The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black or color LSZH sheath,There is a recognition guide at the bottom of the cable.

Product Structure

FTTH Cable GJXFH(V) - Fiber Optical Cables - 1

Product Features

· Special low-bend-sensitivity fiber provides high bandwidth and excellent communication
transmission property;
· Two parallel FRP strength members ensure good performance of crush resistance to protect the
fiber;
· Single steel wire or messengers as the additional strength member ensures good performance of tensile strength;
· Simple structure, light weight and high practicability;
· Novel flute design, easily strip and splice, simplify the installation and maintenance;
· Low smoke, zero halogen and flame retardant sheath.

Optical Characteristics

FTTH Cable GJXFH(V) - Fiber Optical Cables - 2

Technical Parameters

Fiber count	Cable Diameter mm	Cable Weight kg/km	Tensile Strength Long /Short Term N	Crush Resistance Long /Short Term N/100mm	Bending Radius Static /Dynamic mm
1	(2.0±0.2)×(5.0±0.2)	20	300/600	1000/2200	20/40
2	(2.0±0.2)×(5.0±0.2)	20	300/600	1000/2200	20/40
4	(2.0±0.2)×(5.0±0.2)	20	300/600	1000/2200	20/40
6	(2.5±0.2)×(6.0±0.2)	26	300/600	1000/2200	20/40
8	(2.5±0.2)×(6.0±0.2)	26	300/600	1000/2200	20/40
12	(3.0±0.2)×(7.0±0.2)	34	300/600	1000/2200	20/40

Storage/Operating Temperature : -20℃ to + 60℃

Application

Used in indoor cabling, especially used for FTTH

Used as access building cable

1.Are you factory or trading company?

We have 2 big factories, one is for fiber optic cable, the other one is for communication equipments,so we can offer you high quality ,factory price and fast delivery. Welcome to visit our factory, we can pick you up from airport.

2. Can I buy samples before placing orders?

Yes.We are happy to send you sample to test quality.

3.What is your lead time?

-For usual products, we have stock, we can ship out within 3 days. If we don’t have stock,It depends on the quantity , normally 7 days to 15 days.

4.What is your payment term?

30% as deposit, balance before delivery. Or balance againest copy of BL.

5.What is the shipping method?

-By sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect).

6.Can you offer ODM&OEM?

-Yes, we accept ODM&OEM.We have our own R&D team with 18 years experience.

The bulk cargo of optical fiber equipment can be transported by air or by sea; the whole container can be transported by sea. The shipping time for conventional goods is 3-5 days, and OEM goods are generally shipped within 7-10 days. All packaging is in accordance with customer requirements.
